Breakaway Pole Devices

Break-away Couplings

Notes Manufacturer Catalog Number Approval Date Photos
Precision Form, Inc. PFI-200-1A Breakaway Couplings 5/5/03 Coupling
Nut
Label
Transpo Industries, Inc. Couplings: SMP4100
Pole Skirt: SPMKDN-5
5/15/19 Couplings

Break-away Bases

Notes Manufacturer Catalog Number Approval Date Photos
Formerly Akron Foundries, Inc. / Hapco AASHTO No. TB6-9”–10 ½” to 12½” Bolt Circle
Dwg # A79402 – 4/4/98

AASHTO No. TB5-9”–14 ½” to 15¼” Bolt Circle
Dwg # A79236 – 1/4/00
8/15/03 Label
Top View
Bottom View
Side View
Inside Cover Latch
Formerly Akron Foundries, Inc. / Valmont CS-300 – Up to 12” Bolt Circle AASHTO No. TB6-9
7" Diameter Shaft: Model No. 07R115125B9K w/ Rev 1
8" Diameter Shaft: Model No. 08R115125B9K w/ Rev 1

CS-370 – 14 ½” to 15” Bolt Circle AASHTO No. TB5-9
Model No. 10R145153B9K w/ Rev 1
4/23/18 Side View
Top View
Label

Up arrow 66x80.png Top Return to Approved Materials
Side arrow 80x66.png

Cable

#6 AWG Equipment Ground Wire

Notes Manufacturer Catalog Number Approval Date Photos
Advanced Digital Cable BC06S 5/20/16 Bare Copper Cable
Alan Wire Bare No. 6 AWG 7/4/14
Cerro Wire & Cable Co, Inc. 050-2200x or 050-2215x
x = I for 315' Reel
x = K for 1,000' Reel
x = p for 5,000' Reel
5/5/03
Encore Wire LTD Bare No. 6 AWG 8/1/03
Service Wire Co BSOS6 5/7/02
Southwire Bare No. 6 AWG 5/5/03
Comment:
Soft Drawn Bare Solid Copper #6 AWG

Distribution Cable

Notes Manufacturer Catalog Number Approval Date Photos
Advanced Digital Cable 304
UL file # E197262
5/20/16 Mfg Label
AWG Label
Cable
Alan Wire 04USE11 – 500’
UL file #E322440
1/30/12 Cable
Cerro Wire & Cable Co, Inc. 1201-4401x - Black
x = K for 1,000' Reel
x = P for 5,000' Reel

UL file # E11098
5/5/03
Part of Prysmian Group Draka Cableteq 388932 7/8/09 Cable
Label View 1
Label View 2
Label View3
Encore Wire LTD UL file # E174428 8/1/03 E-File Number
End View
Label View 1
Label View 2
Kris Tech Wire Co, Inc. 0407-RHW/USE-BK
UL file # E207792
11/24/03 Cable
Label View 1
Label View 2
Service Wire Co USE4BK
UL file # E105667
5/7/02 Cable
Label
Southwire 11-32-72
UL file # E32071
5/5/03 Cable
Comment:
No. 4 AWG USE-2 Copper
Black insulation
Single cable, not three cables twisted on the reel

Up arrow 66x80.png Top Return to Approved Materials
Side arrow 80x66.png

Pole Cable

Notes Manufacturer Catalog Number Approval Date Photos
Advanced Digital Cable 410 - Black
410RD - Red
410GN - Green
UL file # E208489
5/20/16 Black Cable
Label
Red Cable
Green Cable
Cerro Wire & Cable Co, Inc. Black – 112-3801
Red – 112-3803
Green – 112-3805
UL file # E15119
5/5/03
Encore Wire LTD UL File # E123774 8/1/03 Cable
Republic Wire UL File E167613 5/8/23 Label Name
Label Wire Type
Label UL File
Southwire Red – 22-97-57
Black – 22-97-32
Green – 22-97-73
UL file # E23919
5/5/03
Comment:
Stranded copper
THHN/THWN #10 AWG
Color Coded Red and Black
Green for ground cable

Up arrow 66x80.png Top Return to Approved Materials
Side arrow 80x66.png

Electrical Service Cable

Notes Manufacturer Catalog Number Approval Date Photos
Advanced Digital Cable 302
UL file # E197262
5/20/16 Mfg Label
AWG Label
Cable
Alan Wire Product Number 02USE11 – 500’
UL file #E322440
1/30/12
Cerro Wire & Cable Co, Inc. 1201-4601 - Black
1201-4602 - White
1201-4605 - Green

UL file # E11098
5/5/03
Part of Prysmian Group Draka Cableteq Product Number 389417 7/8/09
Encore Wire LTD UL file # E174428 8/1/03
Kris Tech Wire Co, Inc. 0207-RHW/USE-BK
UL file # E207792
11/24/03
Service Wire Co USE2BK
UL file # E105667
5/7/02 Cable
Label
Southwire 113498 - Black
476523 - White
958009 - Green

UL file # E32071
5/5/03
Comment:
No. 2 AWG USE-2 Copper
Single cable, not three cables twisted on the reel

Up arrow 66x80.png Top Return to Approved Materials
Side arrow 80x66.png

Cable Retainer Device

Notes Manufacturer Catalog Number Approval Date Photos
AB Chance For Type R Foundations:
T1122800
For Type T1 and F1 Foundations:
C1122779
For Type F2 Foundations:
C1122780
6/25/21 Top View
Bottom View
Clamp
JH Botts For Type R Foundations:
AntiTheftGTypeR
For Type T1 & F2 Foundations:
AntiTheftGTypeZTF1
For Type F2 Foundations:
AntiTheftGType860F2
8/17/23 Top View
Pelco 4" For Type R Foundations:
SP-6405-GLV
6" For Type T1, F1, F2 or Concrete Foundations:
SP-6200-GLV
4/7/21 4" Retainer Top View
4" Retainer Bottom View
4" Retainer Edge View
4" Retainer Label
6" Retainer Top View
6" Retainer Bottom View
6" Retainer Edge View
6" Retainer Label
Comment:
The Pelco device shall be installed upside down when using frangible breakaway bases
